Size available : 36", 42",
48"
Straight and Angular |
|
| |
|
|
|
|
SPECIFICATION
| Arm Length |
24"
60mm |
34"
860mm |
40"
1020mm |
46"
1170mm |
52"
1320mm |
66"
1680mm |
| Stitch Size |
12.7mm |
12.7mm |
12.7mm |
12.7mm |
12.7mm |
12.7mm |
| Capacity |
1.6mm to 8mm |
1.6mm to 8mm |
1.6mm to 8mm |
1.6mm to 8mm |
1.6mm to 8mm |
1.6mm to 8mm |
| Driving Pully |
9""Dia A
Type V Belt |
9""Dia A
Type V Belt |
9""Dia A
Type V Belt |
9""Dia A
Type V Belt |
9""Dia A
Type V Belt |
9""Dia A
Type V Belt |
| Speed(App.) |
350 Stitches per min |
350 Stitches per min |
350 Stitches per min |
350 Stitches per min |
350 Stitches per min |
350 Stitches per min |
| Electric Motor |
1 HP
1440 RPM |
1 HP
1440 RPM |
1 HP
1440 RPM |
1 HP
1440 RPM |
1 HP
1440 RPM |
1 HP
1440 RPM |
| Size of Wire Use |
12/25g.
Flat Wire |
12/25g.
Flat Wire |
12/25g.
Flat Wire |
12/25g.
Flat Wire |
12/25g.
Flat Wire |
12/25g.
Flat Wire |
| App.Net Wt.(kg.) |
200 |
230 |
275 |
360 |
400 |
475 |
| App. Gross Wt.(kg.) |
320 |
350 |
400 |
500 |
520 |
625 |
A
(mm.) |
1800 |
1800 |
1800 |
1825 |
1825 |
1825 |
B
(mm.) |
1219 |
1397 |
1524 |
1664 |
1842 |
18994 |
C
(mm.) |
1510 |
1510 |
1510 |
1535 |
1535 |
1535 |
D
(mm.) |
610 |
864 |
1016 |
1169 |
1321 |
1676 |
|
|
